Standard No.	Dimension(mm)
Standard No.	d	Shaft-Φd S	Φdi	Housing ΦDH	Flang Wall (Sf)	Flang Φ(DF)	Length(L ±0.01")
		06FMG04	3/8	0.3750 0.3740	0.4684 0.4691	0.3752 0.3779	0.052 0.044	11/16	1/4
		06FMG06	3/8	0.3750 0.3740	0.4684 0.4691	0.3752 0.3779	0.052 0.044	11/16	3/8
		06FMG08	3/8	0.3750 0.3740	0.4684 0.4691	0.3752 0.3779	0.052 0.044	11/16	1/2
		08FMG04	1/2	0.5000 0.4990	0.5934 0.5941	0.5002 0.5029	0.052 0.044	13/16	1/4
		08FMG06	1/2	0.5000 0.4990	0.5934 0.5941	0.5002 0.5029	0.052 0.044	13/16	3/8
		08FMG08	1/2	0.5000 0.4990	0.5934 0.5941	0.5002 0.5029	0.052 0.044	13/16	1/2
		10FMG06	5/8	0.6250 0.6240	0.7184 0.7192	0.6252 0.6280	0.052 0.044	15/16	3/8
		10FMG08	5/8	0.6250 0.6240	0.7184 0.7192	0.6252 0.6280	0.052 0.044	15/16	1/2
		10FMG10	5/8	0.6250 0.6240	0.7184 0.7192	0.6252 0.6280	0.052 0.044	15/16	5/8
		12FMG06	3/4	0.7500 0.7488	0.8747 0.8755	0.7502 0.7534	0.068 0.060	1 1/8	3/8
		12FMG08	3/4	0.7500 0.7488	0.8747 0.8755	0.7502 0.7534	0.068 0.060	1 1/8	1/2
		12FMG12	3/4	0.7500 0.7488	0.8747 0.8755	0.7502 0.7534	0.068 0.060	1 1/8	3/4
		14FMG08	7/8	0.8750 0.8738	0.9997 1.0005	0.8752 0.8784	0.068 0.060	1 3/8	1/2
		14FMG12	7/8	0.8750 0.8738	0.9997 1.0005	0.8752 0.8784	0.068 0.060	1 3/8	3/4
		14FMG16	7/8	0.8750 0.8738	0.9997 1.0005	0.8752 0.8784	0.068 0.060	1 3/8	1
		16FMG08	1	1.0000 0.9988	1.1247 1.1255	1.0002 1.0034	0.068 0.060	1 3/4	1/2
		16FMG12	1	1.0000 0.9988	1.1247 1.1255	1.0002 1.0034	0.068 0.060	1 3/4	3/4
		16FMG16	1	1.0000 0.9988	1.1247 1.1255	1.0002 1.0034	0.068 0.060	1 3/4	1

As one of the leading inch carbon flange bushings manufacturers and suppliers in China, we warmly welcome you to buy or wholesale inch carbon flange bushings in stock here from our factory. All customized products are with high quality and competitive price. Welcome to contact us for free sample and pricelist.
