Flange Carbon Bushings

Flange Carbon Bushings

MG-1 carbon steel flange self-lubricating bearing uses high quality low-carbon steel plate as backing, sintered porous bronze as its interlayer and the compound of PTFE as its surface. It o ers the property of good self-lubrication, low wear, low friction, good sliding characteristics, low noise etc. It is widely applied in a various mechanical mating parts.

Send Inquiry

Description

◆ Material Structure:

1. PTFE with mixture 0.01~0.03mm

2. Porous bronze 0.2~0.35mm

3. Steel backing 0.7~2.3mm

4. Tin-plating 0.005mm or copper plating 0.008mm

◆ Technical Data:

Technical Data
Max.loadStatic250 N/mm
Very low speed 140N/mm
PV (dry running) Max.Roatating oscillating 60N/mm
Short-term operation 3.6N/mm2·m/s
Continuous operation 1.8N/mm ·m/s
Temp. limit -195℃~+280℃
Friction coenncient 0.02~0.20
Max. speedDry running2m/s
Hydrodynamic operation >2m/s
Thermal conductivity 42 W(m·k)-1
Coenncient of thermal expansion 11×10 ·K
DesignationShaft(Ds) (mm)ToleranceHousing (H7)ToleranceODToleranceID After fixed Di,aClearance DDWall thick- ness S3Dimension(mm)

DiDoD±0.5L±0.25S -0.2



MG-1F060406-0.013 -0.0288+0.0158+0.055 +0.0256.055 5.990.077 0.0001.005 0.980681241


MG-1F060706-0.013 -0.0288+0.0158+0.055 +0.0256.055 5.990.077 0.0001.005 0.980681271


MG-1F080558-0.013 -0.02810+0.01510+0.055 +0.0258.055 7.990.083 0.0031.005 0.980810155.51


MG-1F080758-0.013 -0.02810+0.01510+0.055 +0.0258.055 7.990.083 0.0031.005 0.980810157.51


MG-1F1007010-0.016 -0.03412+0.01812+0.055 +0.02510.058 9.9900.086 0.0031.005 0.98010121871


MG-1F1009010-0.016 -0.03412+0.01812+0.055 +0.02510.058 9.9900.086 0.0031.005 0.98010121891


MG-1F1012010-0.016 -0.03412+0.01812+0.055 +0.02510.058 9.9900.086 0.0031.005 0.980101218121


MG-1F1207012-0.016 -0.03414+0.01814+0.055 +0.02512.058 11.9900.092 0.0061.005 0.98012142071


MG-1F1209012-0.016 -0.03414+0.01814+0.055 +0.02512.058 11.9900.092 0.0061.005 0.98012142091


MG-1F1212012-0.016 -0.03414+0.01814+0.055 +0.02512.058 11.9900.092 0.0061.005 0.980121420121


MG-1F1412014-0.016 -0.03416+0.01816+0.055 +0.02514.058 13.990.092 0.0061.005 0.980141622121


MG-1F1417014-0.016 -0.03416+0.01816+0.055 +0.02514.058 13.990.092 0.0061.005 0.980141622171


MG-1F1509015-0.016 -0.03417+0.01817+0.055 +0.02515.058 14.9900.092 0.0061.005 0.98015172391


MG-1F1512015-0.016 -0.03417+0.01817+0.055 +0.02515.058 14.9900.092 0.0061.005 0.980151723121


MG-1F1517015-0.016 -0.03417+0.01817+0.055 +0.02515.058 14.9900.092 0.0061.005 0.980151723171


MG-1F1612016-0.016 -0.03418+0.01818+0.055 +0.02516.058 15.990.092 0.0061.005 0.980161824121


MG-1F1617016-0.016 -0.03418+0.01818+0.055 +0.02516.058 15.990.092 0.0061.005 0.980161824171


MG-1F1812018-0.016 -0.03420+0.02120+0.075 +0.03518.061 17.9900.095 0.0061.005 0.980182026121


MG-1F1817018-0.016 -0.03420+0.02120+0.075 +0.03518.061 17.9900.095 0.0061.005 0.980182026171


MG-1F1820018-0.016 -0.03420+0.02120+0.075 +0.03518.061 17.9900.095 0.0061.005 0.980182026201
